Moteur Grp Hyd Spliter Sizer Sec 30kW

SD motor type: 1CV3205B

Low-voltage motor, IEC squirrel-cage rotor, self-cooled, IP55 temperature class 155(F) according to 130(B) gray cast iron housing

Basic Line Premium Efficiency IE3, 60 Hz, P60: IE2 4-pole * size 200L, * 30 kW (50 Hz) 34.5 kW (60 Hz)

Standard color RAL 7030 if no order code isspecified for selecting anothercolor.​

3 AC 50 Hz 380 VD/660 VY * 3 AC
60 Hz 440 VD
IM B 35 * Flange: FF350 (A400)
3 PTC thermistors for disconnection (2 terminals) terminal box at top

B02=Acceptance test certificate 3.1 according to EN 10204
H07=Stainless screws (external)
N30=Increased humidity/temp.
With 30 to 60 g water per m3air

R50=Larger terminal box
S04=Special paint finish offshore
S05=Internal coating (metal parts, rotor and stator)
Y53=Paint finish in otherstandard RAL colors (for selection see catalog) RAL..
Y53 = RAL7037

Référence interne: 1LE1503-2AB53-3JB4-Z
